Products

Battery/Supercapacitor Equipments

Coin Cell Battery Equipments

Pouch Cell Battery Equipments

Cylinder Cell Battery Equipments

Battery Test Equipments

Battery Pack Assembly Line

Glove Box

Ball Mill

Battery Materials

Spectroscopy Instruments

Higher performance all-in-one system for Raman and TCSPC/FLIM analysis
Confocal/3D fluorescence lifetime imaging and analysis
Photocurrent imaging and analysis
Nano Cycler
White Light interferometric Profiler

SEM

i.SEM: Bench top SEM

EM-30
EM-30^N
EM-30C

ii.SEM: Full Size SEM

CX-200Plus

iii.Scanning ELectron Microscope for Particle Analysis

iv.Cross Section Polisher: CP-8000

v.Ion Sputter Coater: SPT-20

vi.EDS,DetectorOxford, AZtecOne with Xplore, Compact Bruker: QUANTAX Compact

vii.STEM

viii.Cool Stage: CSU-2

ix.BSE Detector:

Silicon Wafers/Substrates

We carries full range of FZ and CZ silicon wafers, the specifications and parameters comply with SEMI standards.

Prime, test, mechanic grades
Diameter from 2″ to 12″
Ultra thin or ultra thick
Crystalline orientation <100>, <111>, <110>
Most resistivity range
P type/ Boron, N type/Phos, As doped
Heavily doped or intrinsic wafers
Single side polished or double sides polished
Semi-standard flats or notch point
We keep a stock of silicon wafers with various specifications all the time. Contact us for immediate quotation and delivery.

SOI Wafers

Silicon on insulator (SOI) wafers are a three layer material stack composed of the following: an active layer of prime quality silicon (DEVICE LAYER) over a buried layer (BOX) of electrically insulating material (like silicon dioxide, sapphire, silicon nitride, etc), over a bulk silicon support wafer (HANDLE LAYER).

SOI wafers provide a manufacturing solution which helps reduce power and heat while increasing the speed performance of a device. They are widely used for the fabrication of micro electro mechanical system, micro optical devices, sensors, RF switches, power devices, and advanced CMOS IC chips. SOI wafers are unique products which are often custom-built for specific end-user applications.

BondaTek is able to meet customer’s needs for SOI wafers with diameter from 76.2mm to 300mm. We accommodate SOI requests for development of small quantities as well as ongoing requirements.

Solar Wafer

Material: Monocrystalline Silicon
size: 125mm x 125mm and 156mm x 156mm
Application: Solar System
Packing: Carton
Color: Grey
Advantage: high quality/ short lead time/ low price/ customization
specifications:Conductive Type: N type/ Phos doped
Orientation: <100>=/-3 degree
Resistivity: 1 – 3, 3- 6 ohm.cm
Bulk lifetime: >=1000us
Oxygen Content: <=0.1*10^18cm^3 Carbon Content: <=0.1* 10^17cm^3
Thickness: 200+/-20um TTV: <=25UM Saw Mark:<=15um Warp :<=40um
Chips: Depth <0.3mm, length <0.5mm Less than 2 chips per wafers
Appearance: No stain, No Pinhole and cracks by Visual Inspection Dislocation Density: =1000pcs.cm^2

Sputtering Targets

Metal sputtering targets
Alloy sputtering targets
Ceramic sputtering targets

Evaporation Materials

Evaporation Materials: Evaporation Materials ,also called E-beam materials ,are used for thin film deposition for a wide application. We can provide full production line.

Metal evaporation material
Oxide evaporation materials
Fluoride evaporation materials
Others

Electron Microscopy Products

Different Grids, TEM Support Films
TEM Window
Films for TEM
SEM Accessories
Atomic Force, Scanning Tunneling Microscopy
Transmission Electron Microscopy
Histology & Light Microscopy
Tweezers, Tools, Gadgets
Different Tapes, Pastes & Dispensers
Diamond Knife

So on…

Nanometer Materials

Metal powder: Nickel, Aluminum,Silver, Gold etc
Oxide Nano powder: Titanium, Silicon, Cobalt etc
Compound Nano powder: Yittria Stabalized Zirconia, Zinc Iron Oxide, Aluminum Nitride, Boron Nitride etc
Micro powder : Bismuth Oxide, Barium Titanate, Aluminium Oxide etc
OTHERS: Glass Wafers, single crystal wafers, Sapphire Wafers, SOS Wafers, GE, SRTIO3, MGO etc.,
